Interface Board
4K Optical Interface Boards
High-performance 4K optical interface boards designed for OEM integration into custom systems. Compact form factor enabling system integrators to add fiber optic connectivity to any platform.
Features
Key Capabilities
4K UHD Support
Full 3840x2160 uncompressed video at up to 60 fps.
Compact Form Factor
Board-level design for easy integration into custom enclosures and OEM systems.
Input interface
Supports TDM interface.
Extended Temperature
Use of electrical and optical parts to meet industrial temperature range for demanding environments.
Low Power Consumption
Optimized power design for embedded and portable applications.
Specifications
Technical Details
Video
| Max Resolution | 3840 x 2160px |
| Frame Rate | Up to 60fps |
| Input Interfaces | TMDS |
Optical
| Fiber Type | Multi-mode / Single-mode |
| Wavelength | 850 nm / CWDM (1270/1290/1310/1330nm) |
| Max Distance | 300 m (MM) / 40 km (SM) |
| Connector | MPO12 (MMF) / LC (SMF) |
Mechanical
| Dimensions | 50.0 × 65.0 mm (excl. protrusions) |
| Power | 2 W max. |
| Operating Temp | -5 ~ +60°C |
| Mounting | Board-level |
.jpg&w=3840&q=75)
Resources
Downloads
Interested in 4K Optical Interface Boards?
Contact our engineering team to discuss your application requirements and get detailed specifications.
