8K / 16K Optical Transmission Devices
Industry-leading optical transmission devices delivering uncompressed 8K and 16K video signals over single-mode fiber. Designed for broadcast, medical, and defense applications where ultra-low latency, low loss transmission is non-negotiable.
Features
Key Capabilities
8K / 16K Resolution
Native support for 7680x4320 (8K) and 15360x8640 (16K) uncompressed video formats.
Ultra-Low Latency
No signal compression ensuring real-time signal delivery for live production and surgical applications.
Long-Distance Transmission
Reliable fiber optic transmission over distances up to 40 km without signal degradation.
Mission-Critical Reliability
Redundant designs of power supplies and optical fibers for applications where downtime is not an option.
System Integration Ready
Hardware redundancy design of the key modules, and SNMP and GUI functions are all integrated into a 3U rack device, eliminating the need for additional functions.
Proprietary FPGA Design
Proprietary FPGA-based signal processing for optimal performance and flexibility.
Specifications
Technical Details
Video
| Max Resolution | 15360 x 8640px |
| Compression | None (Uncompressed) |
Optical
| Fiber Type | Single-mode (SM) |
| Wavelength | C-band 50 GHz spacing |
| Max Distance | 40km |
| Connector | SC |
General
| Form Factor | 3U Rack Mount |
| Power Supply | Redundant AC |
| Operating Temp | 0 ~ 45°C |
| Management | SNMP / Web GUI |
.jpg&w=3840&q=75)
.jpg&w=3840&q=75)
Resources
Downloads
Interested in 8K / 16K Optical Transmission Devices?
Contact our engineering team to discuss your application requirements and get detailed specifications.
